ブランド名:
Greef
証明:
CE
Model Number:
TYP
TYP Magnet motors are equipped with rotors that incorporate permanent magnets. This advanced design brings numerous benefits to the motor's performance.
One of the key advantages of this technology is its enhanced efficiency, alongside a higher power density in relation to the motor’s frame size. These features make TYP Magnet motors stand out in various applications requiring compact and powerful solutions.
These motors are powered by frequency inverters, which enable them to deliver consistent torque across a broad range of speeds. This capability ensures efficient operation even at low speeds, surpassing the performance of traditional induction motors without the need for forced ventilation systems.
Additionally, W21 Magnet motors are designed for low-speed operation and generate minimal noise, contributing to energy savings and quieter working environments.
This motor achieves energy savings of up to 30% compared to traditional induction motors powered by inverters. It maintains high efficiency over a broad load range, from 20% to 110% of its rated capacity, resulting in measured energy savings between 10% and 40%.
Additionally, it boasts a very high power factor close to 1.0 at rated load, and consistently above 0.95 across operating conditions. This reduces stator current and minimizes copper losses.
The motor delivers a consistent torque output over a wide range of speeds without the need for forced ventilation. It is well-suited for applications that require variable speed operation combined with constant torque, even at low speeds, and it does not require the use of an encoder.
Its bearings provide an L10 life expectancy of up to 100,000 hours, equivalent to over 10 years of continuous operation. Furthermore, the inclusion of grease nipples allows for easy re-lubrication, reducing the frequency and duration of maintenance downtime.
Equipped with high-performance NdFeB (Neodymium-Iron-Boron) rare-earth magnets, which are about 18 times stronger than conventional ferrite magnets, this motor ensures outstanding magnetic performance. These magnets are protected by an epoxy coating that enhances mechanical strength and corrosion resistance.
The motor incorporates PTC (Positive Temperature Coefficient) thermistors within the windings. This embedded thermal protection safeguards the motor against overheating caused by phase loss, overload conditions, and voltage irregularities.
As a synchronous motor, its rotor speed is synchronized with the stator’s rotating magnetic field, eliminating slip and rotor power losses. This synchronization ensures stable operation, with speed unaffected by changes in voltage or load, thereby enhancing control precision.
Utilizing a maximum torque/current ratio control mode enables the motor to maintain a high power factor throughout its entire speed range. This results in a significant reduction of stator current by 15% to 30%, which in turn lowers cable transmission losses and effectively increases cable capacity.
Thanks to its high efficiency and low loss characteristics, the motor experiences a temperature rise that is 15 to 20°C lower than comparable asynchronous motors operating under the same conditions.
This motor is widely applied across various industries including injection molding, air compression, pipe manufacturing, hydraulic machinery, food processing, extrusion, wire drawing, and pharmaceuticals. It must be paired with a dedicated permanent magnet motor inverter for optimal performance.
For example, replacing a 37kW IE2 (GB3) induction motor with this permanent magnet motor can save approximately 9,000 RMB annually in energy expenses, assuming continuous 24/7 operation.
The TYP series high-efficiency permanent magnet frequency conversion synchronous motors are highly versatile and reliable. They have been extensively utilized across various industries due to their superior performance and energy-saving capabilities.
These motors find wide applications in injection molding machines, where precision and efficiency are critical. Additionally, they are commonly employed in air compressors and pipe making equipment, contributing to enhanced operational stability and reduced energy consumption.
Moreover, the TYP series motors are ideal for hydraulic machinery and food processing machines, offering consistent and efficient power delivery. Their use also extends to cement pipe manufacturing machines, plastic extruders, wire drawing machines, and pharmaceutical equipment, demonstrating their adaptability in diverse mechanical environments.
Greef offers comprehensive product customization services for our Permanent Magnet Motor, model TYP. Originating from China and certified with CE, this high power density motor is designed to meet diverse industrial needs. We specialize in synchronous magnet motors that are customizable for low speed applications, with a speed range of 0-8000 RPM to suit various operational requirements.
Our Permanent Magnet Motor features premium SKF bearings to ensure durability and optimal performance. Ideal for electric vehicles, robotics, and industrial automation, this motor combines reliability with efficiency. We accept a minimum order quantity of 1 set, with pricing negotiable based on your specific customization needs.
Packaging is handled with care using foam and plywooden cases to guarantee safe delivery. Our delivery time is approximately 25 working days, and we offer flexible payment terms including T/T, Western Union, MoneyGram, and L/C. Greef is committed to providing supply ability that meets your project timelines and quality expectations.
Our Permanent Magnet Motors are carefully packaged to ensure they arrive in perfect condition. Each motor is securely wrapped with protective materials to prevent damage during transit. The motors are then placed in sturdy, custom-designed boxes that provide additional cushioning and support.
For shipping, we use reliable carriers with tracking options to guarantee timely and safe delivery. Depending on the order size and destination, motors may be shipped individually or in bulk pallets, all handled with utmost care to maintain product integrity.
We also offer customized packaging solutions upon request to meet specific requirements. Please contact our customer service team for more information on special packaging or shipping needs.
