On Grid Controller with Rectifier Control and DC Output Functions for Wind Generator Systems

Rectifier Function On Grid Controller

Control Function Grid-Tied Controller

DC Output Function Wind Generator Controller

ブランド名:

Greef

証明:

Model Number:

GT-PCTC Series Controller

連絡ください

引金を求めてください

製品詳細

製品タイプ:

超電圧保護ネットワーク切断保護制御電源出力停止

格子監視:

はい

冷却方法:

自然のコンベクション

関数:

矯正器,制御器,DC出力

保護の程度:

IP20 (室内) IP65 (屋外)

PWM常電圧:

≥400dc, ≥700dc

MPPT効率:

99.9％

出力周波数:

50Hz/60Hz

支払いと送料の条件

Minimum Order Quantity

1Set

価格

negotiable

Packaging Details

Foam+plywooden Case

Delivery Time

25 Working Days

支払条件

T/T、ウェスタンユニオン、マネーグラム、L/C

Supply Ability

AC Generator-Battery Hybrid Converter with 450 Vac Optimal Generator Rated Voltage and LCD SMART Touch Screen Display for 50/60 Hz Rated Grid Frequency

最高の価格を入手する

LCD Smart Touch Screen On Grid Controller with 240-550V AC Voltage Range and 95% Maximum Efficiency for Energy Management

最高の価格を入手する

AC Generator-Battery Hybrid Converter with 95% Maximum Efficiency and 240-550V AC Voltage Range Featuring RS485 Communication Mode

最高の価格を入手する

95% Maximum Efficiency On Grid Controller with LCD Smart Touch Screen and Lithium-Ion Battery for Energy Management

最高の価格を入手する

連絡ください

今連絡してください

製品説明

Wind Turbine Grid-Tied Controller AC220V-600V with Manual Function and Emergency Switch

Product Overview

The Grid-Tied Controller is a critical component for wind generator systems connected to the power grid. This advanced controller converts three-phase AC current from wind turbines into DC current for grid-tie inverters, featuring dual safety systems (PWM constant voltage and three-phase dump load brake) for optimal performance and reliability.

Key Features

Compatible with leading solar inverters (Growatt, Deye, Solis, lvet)
Double safety control systems for enhanced protection
LCD touch screen display with comprehensive monitoring
Manual brake, reset, and emergency switch functions
Multiple protection features including over voltage and grid cut-off
Optional communication interfaces (RS485/USB/GPRS/WIFI/Ethernet)

Technical Specifications

Type	GT-PCTC-1.5KW	GT-PCTC-2KW	GT-PCTC-3KW	GT-PCTC-5KW
Wind turbine rated power	1.5KW	2KW	3KW	5KW
Wind turbine rated voltage	AC220V-240V	AC220V-240V	AC220V-380V	AC380-450V
PWM constant voltage	≥400dc	≥700dc	≥700dc	≥700dc

Type	GT-PCTC-10KW	GT-PCTC-20KW	GT-PCTC-30KW	GT-ACDC-50KW	GT-ACDC-100KW
Wind turbine rated power	10KW	20KW	30KW	50KW	100KW
Wind turbine rated voltage	AC380-520V

General Specifications

Environment temperature: -30-60°C
Relative humidity: ＜90% (No condensation)
Noise (1m): ＜40dB
Degree of protection: IP20 (Indoor) / IP65 (Outdoors)
Cooling method: Forced air cooling

Greef has a professional team to create tailor-made systems for customers. The images shown are examples - contact us for custom requirements.

Applications

Designed for grid-connected systems including wind power generation, hydroelectric power generation, and solar power generation applications.

Customization Options

Brand Name: Greef
Model Number: GT-PCTC Series Controller
Certification: CE
Minimum Order Quantity: 1 Set
PWM Constant Voltage: ≥400dc, ≥700dc
MPPT Efficiency: 99.9%

Packaging & Shipping

Package Includes: Controller unit, user manual, mounting hardware
Packaging: Foam + plywood case
Delivery Time: 25 working days
Payment Terms: T/T, Western Union, MoneyGram, L/C
