家へ > 製品 > 格子コントローラー >
1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用)

1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用)

湿度感のある風制御器

地面欠陥監視風制御装置

Place of Origin:

Qingdao

ブランド名:

Greef

証明:

CE

Model Number:

GT-PCTC Series Controller

連絡 ください
引金 を 求め て ください
製品詳細
最大効率:
97%
通信用インタフェース(任意):
RS485/USB/GPRS/WIFI/イーサネット
出力周波数:
50Hz/60Hz
表示モード:
LCDタッチスクリーン
製品タイプ:
ネットワークに接続された風制御装置
地上の欠陥の監視:
はい
風力タービン名電圧:
AC380-520V
相対湿度:
<90% 凝縮物がない
ハイライト:

湿度感のある風制御器

,

地面欠陥監視風制御装置

支払いと送料の条件
Minimum Order Quantity
1Set
価格
交渉可能
Packaging Details
Foam+plywooden case
Delivery Time
25 working days
支払条件
T/T、ウェスタンユニオン、マネーグラム、L/C
Supply Ability
Supply Ability
製品説明
1.5KW-100KW 地絡監視風力追跡コントローラー(湿度に敏感な用途向け)
製品紹介
1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 0

GREEF PCTCシリーズ WIND TRACKER CONTROLLER(1KW-100KW)は、最新の風力エネルギーシステム向けに特別に設計されたインテリジェントコアコンポーネントです。市場の主要な太陽光発電インバーターと互換性があり、小型風力タービンのグリッド接続インバーターのコストと認証の課題を解決します。また、高度な監視、保護、リモート管理機能を統合しています。

正確な速度-電力曲線制御により、風力発電の効率と安定性を確保します。同時に、革新的なノイズ制御技術により、周囲の環境との調和のとれた共存を実現します。

製品パラメータ
タイプ PCTC-1.5KW PCTC-2KW PCTC-3KW PCTC-5KW
風力タービン定格出力 1.5KW 2KW 3KW 5KW
風力タービン定格電圧 AC220V-240V AC220V-240V AC220V-380V AC380-450V
機能 整流、制御、DC出力
自動保護機能 過電圧保護、グリッド遮断保護、安定化電源出力、アレスタ
手動機能 手動ブレーキ、リセット、緊急スイッチ
表示モード LCDタッチスクリーン
表示内容(大きい方) 発電機速度(rpm)、入力電圧(Vdc)、入力電流(Vac)、出力電力(kW)、グリッド電圧(Vac)、グリッド電流(A)、本日の発電量(kWh)、今月の発電量、先月の発電量、今年の発電量、昨年の発電量、電力曲線設定。
3相ダンプ負荷タイムラプス 12-20分 12-20分 12-20分 12-20分
風力タービン3相ダンプ負荷電圧 450±5Vdc 750±5Vdc 750±5Vdc 750±5Vdc
PWM定電圧 ≥400dc ≥700dc ≥700dc ≥700dc
環境温度 -30-60℃
相対湿度 <90% 結露なきこと
ノイズ(1m) <40dB
保護等級 IP20(屋内) IP65(屋外)
冷却方式 強制空冷
通信インターフェース(オプション) RS485/USB/GPRS/WIFI/Ethernet
タイプ PCTC-10KW PCTC-20KW PCTC-30KW PCTC-50KW PCTC-80KW PCTC-100KW
風力タービン定格出力 10KW 20KW 30KW 50KW 80KW 100KW
風力タービン定格電圧 AC380-520V AC450-600V
自動保護機能 過電圧保護、グリッド遮断保護、安定化電源出力、アレスタ
手動機能 手動ブレーキ、リセット、緊急スイッチ
表示モード LCDタッチスクリーン
表示内容(大きい方) 発電機速度(rpm)、入力電圧(Vdc)、入力電流(Vac)、出力電力(kW)、グリッド電圧(Vac)、グリッド電流(A)、本日の発電量(kWh)、今月の発電量、先月の発電量、今年の発電量、昨年の発電量、電力曲線設定。
PWM定電圧 ≥700dc
風力タービン3相ダンプ負荷電圧 750±5Vdc
風力タービン3相ダンプ負荷タイムラプス 12-20分
環境温度 -30-60℃
相対湿度 <90% 結露なきこと
ノイズ(1m) <40dB
保護等級 IP20(屋内) IP65(屋外)
冷却方式 強制空冷
通信インターフェース(オプション) RS485/USB/GPRS/WIFI/Ethernet
1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 1 1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 2 1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 3 1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 4
製品詳細
1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 5
システムソリューション
1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 6
Greefは、お客様に合わせたオーダーメイドのシステムを作成する専門チームを擁しています。この画像はその一例です。他に要件がある場合は、お問い合わせください!
製品パッケージ
1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 7
なぜ私たちを選ぶのか
1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 8 1.5KW-100KW 風力追跡コントローラー(地絡監視およびLCDタッチスクリーン付き、風力エネルギーシステム用) 9
  • 高度な監視および保護システム
  • 主要な太陽光発電インバーターとの互換性
  • 最適な効率のための正確な速度-電力曲線制御
  • 革新的なノイズ制御技術
  • 包括的なリモート管理機能
  • 専門的なカスタムシステムソリューション
